نظرة عامة
The reciprocating sieve plate extraction tower mainly uses reciprocating sieve plates to break up the dispersed phase into small droplets based on the extraction principle, thereby expanding the mass transfer area of the unit dispersed phase liquid and increasing the mass transfer coefficient, thereby achieving the purpose of efficient extraction. Work flow: The light phase and the heavy phase enter the extraction tower from the lower part of the tower and the upper part of the tower respectively. In the tower, the two phases contact each other in countercurrent. Under the action of the reciprocating sieve plate, a small droplet dispersed phase is formed. Through the countercurrent flow of the dispersed phase and the continuous phase Through contact, one or several components in the material are selectively dissolved in a continuous solvent for mass transfer. Suitable for processing easily emulsifiable systems.
المميزات
● الإنتاج المستمر
يعتمد برج الاستخراج طريقة الإنتاج المستمر، مما يسمح بالتشغيل المستقر والمستمر، مما يعزز كلاً من كفاءة الإنتاج وجودة المنتج.
● Small footprint, large processing capacity, low solvent usage
Due to its unique structural design, the Yuanhuai extraction tower has a relatively small footprint, enabling large-scale processing in limited spaces, thus improving production efficiency. Additionally, this extraction tower uses a relatively small amount of solvent, reducing production costs while also being more environmentally friendly.
● Low pressure drop, high mass transfer efficiency
The extraction tower features a low pressure drop, which reduces the energy consumption and wear of the equipment, thereby extending its service life. It has high mass transfer efficiency, enabling efficient material transfer and separation, which improves the quality and purity of the products.
● دعم الخدمات المخصصة
It can be customized according to client requirements. The materials are generally divided into high borosilicate glass, 304 stainless steel, 316L stainless steel, titanium alloy, etc.The number, spacing and other structures of the sieve plates can be calculated and provided based on the performance of the material and the required degree of separation and purity.Three operating modes are available: fully automatic, semi-automatic, and manual operation.
تطبيقات نموذجية
ويستخدم برج الاستخلاص على نطاق واسع لفصل وتنقية المخاليط السائلة ويجد تطبيقات واسعة في التخمير والهندسة الحيوية والمواد الكيميائية الدقيقة.
معلمة المنتج
Glass extraction tower structure:
Yuanhuai YRET series glass reciprocating sieve plate extraction tower is mainly composed of a reciprocating sieve plate extraction tower, light phase tank, heavy phase tank, extraction liquid tank, raffinate liquid phase tank, motor stirring system, inlet and outlet delivery pump, control system, etc.
| الموديل |
YRET-25 |
| الخامة |
ارتفاع البورسليكات 3.3 |
| قدرة المعالجة |
10L / ساعة |
| قطر برج الاستخراج |
25mm |
| استخراج الارتفاع الفعال |
1500mm |
| خزان المرحلة الخفيفة |
10L |
| خزان المرحلة الثقيلة |
10L |
| زجاجة التجميع |
10L |
| خزان رافيناتي |
10L |
| خزان عازل |
2 لتر * 2 |
| محرك تنظيم السرعة ومخفض السرعة |
370w |
| مضخة التغذية (اختياري) |
مضخة تمعجية*2 |
| بعد |
900 * 800 * 3700mm |
| الوزن |
55kg |
